EXOGEN Setup

First Use

EXOGEN has a calendar which tracks how often the system is used.
The current hour needs to be set to make sure the calendar is accurate.
The hour must be set once, the very first time EXOGEN is turned on.

Hour Setting

1. Press the button once. The hour and AM/
PM show on the screen. This may or may
not be your current hour. The clock must be
set to your current hour. For example, if
your time is anywhere between 2:00 PM
and 2:59 PM, set the hour to 2 PM.
Press button
2. Press the button once to advance the time
one hour. Press the button, one press at a
time, until the correct hour and AM/PM is
displayed on the screen.
8
Flashing hour set screen
3. Press and hold button until you see the
hour confirmation screen. This indicates
that the hour has been set on EXOGEN.
You do not need to set the minutes. After
5 seconds the device will beep and
10
automatically turn off.
9
Current hour
®
www.exogen.com
Start-up screen Hour set
9
AM AM
Press button once to Press button once to
advance hour advance hour
10
AM AM Contact Customer Service at
1-800-836-4080 if you have
Hour Set incorrectly set the hour and
would like to reset it.
Press &
Note: EXOGEN will effectively
hold
deliver treatment even if the
correct hour is not selected.
Confirmation screen

Treating Your Fracture

Start Treatment

Hold EXOGEN in your hand to view the screen, or
set EXOGEN down on a nearby flat surface.
Perform the following steps to begin treatment:
1. Press the button on EXOGEN.
EXOGEN beeps and the start-up screen
appears for 2 seconds.
8
2. A calendar appears on the screen for 5
AM
seconds. It shows the current month and
your treatment summary. For more
information on the calendar screen, see
"Tracking Your Treatment" on
page 13.
3. Next, the 20-minute countdown timer
appears on the screen. EXOGEN auto-
matically begins the ultrasound treatment.
A treatment symbol flashes as the timer
counts down. This means you are treating
your fracture. (Note: To stop EXOGEN in
the middle of the 20-minute treatment,
press and hold the button until EXOGEN
turns off.) If your EXOGEN has an error
10
AM during treatment, see "Troubleshooting"
on page 20.
4. When the countdown timer reaches zero,
EXOGEN beeps and shows the treatment
complete checkmark.The treatment
complete checkmark displays for 5
seconds. Then, EXOGEN beeps and
turns itself off.
www.exogen.com
Press button Start-up screen
August 2013
S M T W T F S
1 2 3
4 5 6 7 8 9 10
11 12 13 14 15 16 17
18 19 20 21 22 23 24 Time Remaining
20:00
25 26 27 28 29 30 31
® treatment summary
100
%
treatment days = 0
0
total days =
compliance
Calendar Treatment countdown
Treatment Complete
Completion
®
