Raptor
RP120
Opening your life
Code:
10) Manual release
Don't worry about the power failure, the manual release system is a solution for operation the door at any time.
11) Transmitter technology
Rolling Code technology (7.38 x 1019 Combinations), 433.92 Mhz frequency, 4 channels design to ensure you can control 4
di erent doors with one transmitter.
12) Lower headroom
With as little as 30mm required between the ceiling and the highest point of the door travel, the opener can be ush moun-
ted for low headroom applications.
13) Metal bottom plate, stronger and security.
14) Up / Down moving operation buttons (UP / DOWN)
UP
Moving up
DOWN
Moving down
B
Figure 1

Pre-installation recommendations

1) Garage door must be able to be lifted and closed easily by hand and without much e ort. A well balanced & sprung door
is critical for proper installation.
2) The garage door opener can't compensate for a badly installed garage door and should not be used as a solution for a
"hard to open" door.
3) If the unit is being installed on an existing door, make sure any existing locking devices are removed or warranty will be
void.
4) An approved outlet must be installed near where the opener is begin installed.
5) There should be a minimum gap of 30mm between the bottom of the chain drive rail and the top of the garage door at
its closest point. (refer to Figure 2.)

Important :

As for additional safety rules, we strongly recommends the tting of Photo Electric safety beams on all installations.
www.accessmatic.com
Opening your life
3
