CHASSIS

775 Brushed Motor
Steering Servo Electronic
Speed Control

REMOVING THE BODY

• Remove hook pin, Remove the body ( Ford 150 Version only )

INSERTING THE DRIVE BATTERY

1 Remove the body
2 Insert the battery.
Advice
• Non-rechargeable batteries are not to be recharged.
• Rechargeable batteries are to be removed from the toy before being charged.
• Rechargeable batteries are only to be charged under adult supervision.
• Batteries are to be inserted with the correct polarity.
• Exhausted batteries are to be removed from the toy.
• The supply terminals are not to be short-circuited.
• Regular examination of transformer or battery charger for any damage to their cord, plug,
enclosure and other parts.
Rear Diff
Lock Servo
Transfer Case
Shifting Servo
Front Diff Lock Transmission
Servo Shifting Servo
RECEIVER PORT
Receiver
CH1: Steering Servo
CH2: Brushed ESC
CH3: 2WD/4WD Shifting
CH4: 2 Speed Shifting Servo
CH5: Front Diff Lock Servo
CH6: Rear Diff Lock Servo
• Loosen magnets, Remove the body
Battery
Brushed Motor
