Modine AGC Serie Manual Tecnico página 32

Ø315-Ø350 fan diameter unit
no. 1
no. 2 ...
= yellow-green
L = brown
N = blue
SD = junction box
Heater connection diagram
Important. Application of adequate thermal control systems on feeder lines is mandatory. Performance of all electric
heaters must be periodically controlled to avoid damage due to ice build-up. Modine is not liable in any way for defects
caused by non detected malfunctions. For models supplied with wiring in a junction box, remove the cover to make the
connection. It is compulsory to use power cables with a minimum cross-section according to the technical standards
in force in the country of installation, depending also on the laying method, the length of the cables and their type. To
minimise the risk of indirect contact, it is advisable to earth the unit, using the earth pole (where present). For further
information please refer to the diagrams supplied with the model.
Ø250 fan diameter unit
400V/3/50-60Hz connection
RBB - Low power heater in coil
RSB - Low power heater on inner drip tray
Model
Rows
Total power
32
www.modine.com
SD
N L
L
N
STANDARD
R
N
S
T
RBB4
RBB3
RBB2
RBB1
RSB1
N
N
U
R
V
S
W
T
P.E.
AGC "ED" 251E4R
Ø250 251E6R
251E8R
4
W 625
no. 2 ...
230V/1/50-60Hz connection
to be set
RBB4
RBB3
RBB2
RBB1
RSB1
N
L
251E4 252G4 252E4
251E6 252G6 252E6
251E8 252G8 252E8
4 3 4
1125 2250 2250
no. 1
SD
230V / 1 / 50-60Hz
L
N
N
L
P.E.
253G4 253E4 254G4
253G6 253E6 254G6
253G8 253E8 254G8
3 4 3
3325 3325 4375
254E4
254E6
254E8
4
4375
