SQUARE WAVE® TIG 200
OPERATION
GRAPHIC SYMBOL USED IN THE MANUAL OR BY
THIS MACHINE
INPUT POWER
ON
OFF
HIGH TEMPERATURE
CIRCUIT BREAKER
POSITIVE OUTPUT
NEGATIVE OUTPUT
3 PHASE INVERTER
INPUT POWER
THREE PHASE
DIRECT CURRENT
