Installation Manual of Room Air Conditioner
Preparation
Necessary Tools for Installation
Driver
Nipper
Hacksaw
Hole core drill
Spanner(17,19 and 26mm)
Gas leakage detector or
soap-and-water solution
Power Source
Before inserting power plug into receptacle, check the voltage without fail.
The power source is the same as the
Install an exclusive branch circuit of the power.
A receptacle shall be set up in a distance where the power cable can be
reached.Do not extend the cable by cutting it.
Drawing for the installation of indoor and outdoor units
The models adopt HFC free refrigerant R410A
more than 5cm
more than 10cm
Indoor unit B
Indoor unit C
Arrangement of piping
directions
Rear left
Rear
Left
right
Right
Below
The marks from
to
A
in the figure are the
G
parts numbers.
The distance between
the indoor unit and the
floor should be more
than 2m.
Please be subject to the actual product purchased , the above picture is just for your reference.
Read this manual before installation
Explain sufficiently the operating means to the user according to this manual.
NO.0010531141
All manuals and user guides at all-guides.com
Torque wrench
(17mm,22mm,26mm)
Pipe cutter
Flaring tool
Knife
Measuring tape
Reamer
corresponding name plate.
Indoor unit A
more than 10cm
more than 10cm
more than 60cm
Selection of Installation Place
Indoor Unit
Place, robust not causing vibration, where the body can be supported sufficiently.
Place, not affected by heat or steam generated in the vicinity, where inlet and outlet of the
unit are not disturbed.
Place, possible to drain easily, where piping can be connected with the outdoor unit.
Place, where cold air can be spread in a room entirely.
Place, nearby a power receptacle, with enough space around. (Refer to drawings).
Place where the distance of more than lm from televisions, radios, wireless apparatuses
and fluorescent lamps can be left.
In the case of fixing the remote controller on a wall, place where the indoor unit can
receive signals when the fluorescent
Outdoor Unit
Place, which is less affected by rain or direct sunlight and is sufficiently ventilated.
Place, possible to bear the unit, where vibration and noise are not increased.
Place, where discharged wind and noise do not cause a nuisance to the neighbors.
Place, where a distance marked
Attention must be paid to
the rising up of drain hose
D
C
D
E
more than15cm
lamps in the room are lightened.
is available as illustrated in the above figure.
Optional parts for piping
Non-adhesive tape
A
Adhesive tape
B
Saddle (L.S) with screws
C
Connecting electric cable
D
for indoor and outdoor
E
Drain hose
F
Heating insulating material
Piping hole cover
G
Floor fixing dimensions of the
outdoor unit (Unit:mm)
113.5
113.5
633
Fixing of outdoor unit
Fix the unit to concrete or block
with bolts (10mm) and nuts firmly
and horizontally.
When fitting the unit to wall
surface, roof or rooftop, fix
a supporter surely with nails
or wires in consideration of
earthquake and strong wind.
If vibration may affect the
house, fix the unit by attaching a
vibration-proof mat.
Tabla de contenido
loading

Resumen de contenidos para Haier 3HUM18HB03/R2(DB)

  • Página 5: Preparación

    All manuals and user guides at all-guides.com Manual de instalación de aparato de aire acondicionado Preparación Herramientas necesarias para realizar la instalación Selección del lugar de instalación Unidad interior Destornillador Llave dinamométrica (17mm, 22mm, Coloque la unidad sobre una superficie que pueda soportarla correctamente y no 26mm) provoque vibraciones.
  • Página 6 All manuals and user guides at all-guides.com [ Entubación trasera ] Accesorios Extraiga los tubos y la manguera de drenaje y fíjelos con cinta adhesiva [Izquierda ・Entubación trasera izquierda] En caso de realizar la entubación por el lado izquierdo, corte con una cuchilla la cubierta de la entubación izquierda.
  • Página 7: Unidad Exterior

    All manuals and user guides at all-guides.com Unidad exterior Instalación de la unidad exterior Instale la unidad exterior de acuerdo con el diagrama de instalación de unidades interiores y exteriores. Conexión de los tubos Al conectar el cable, confirme el número de terminales de las unidades Nota Para doblar un tubo, intente hacer la curva lo más suave posible para no aplastar el interior y exterior detenidamente.
  • Página 8 All manuals and user guides at all-guides.com ¿No existen fugas de gas? En caso de que exista una fuga de gas, apriete las conexiones de los tubos. Si la fuga se detiene, proceda al paso 6. Si la fuga de gas no se detiene, descargue todo el refrigerante a través del puerto de Delgado Daño de conicidad Grieta Parcial Demasiado fuera mantenimiento.
