Carton Inventory

Your garage door opener is packaged in one carton which
contains the motor unit and all parts illustrated below.
Accessories will depend on the model purchased. If anything is
missing, carefully check the packing material.
Premium Motion-Detecting
Control Panel
Idler Pulley
(In Hardware Bag)
Rail
Front (header)
Section
Safety Reversing
Sensor Bracket (2)
Hardware Bag
3-Button Remote Control (2)
Sprocket cover
with screws (3)
Motor Unit with 2 Light Lenses
Header Bracket
The Protector System
(2) Safety Reversing Sensors
(1 Sending Sensor and 1 Receiving Sensor)
with 2-Conductor White and White/Black
Bell Wire attached
Hardware for assembly and installation is shown on the next
page. Save the carton and packing material until installation and
adjustment is complete.
Battery
Trolley
Rail
Center/Back
Sections
Belt
Door Bracket
2-Conductor Bell Wire
White and White/Red
®
Safety Labels
and Literature
8
Wireless Keypad
"U" Bracket
Hanging Brackets
(packaged inside the front rail)
Curved Door
Arm Section
Straight Door Arm Section
(packaged inside the front rail)
