How to use "Opener-tool" to open UK safety
sockets:
To get access to the live and neutral pin of a UK safety
socket you have to release the safety covers first. This
could be easily done by pressing the "Opener-tool" into
earth pin of the socket.

How to use storage area for "GS 38 protective

probe cap":

1
W
Disconnect the voltage tester completely from any
measuring circuit first.
• Pull out the "GS 38 protective cap" 1 out of the "test
probe protector cover", place onto the test probe tips
2 and push firmly to secure it.
• For removal and storage 3 , please perform the
opposite operation.
How to use storage area for "4mm Ø test probe
extension":
6
4
5 7
W
Disconnect the voltage tester completely from any
measuring circuit first.
• To retrieve push the "test probe tip" into the "4mm Ø
test probe extension" 4 and twist right it approx.. ¼
turn 5 .
• Then pull on probe 6 to remove "4mm Ø test probe
extension" and continue twisting until "4mm Ø test
probe extension" is tight 7 .
• For removal please do the opposite way 8 and store
it as shown in last picture.
11
3
2
8
