PRODUCT OVERVIEW & OPERATIONS PRODUCT OVERVIEW & OPERATIONS
Air filters
Front panel
Vertical airflow
direction louver
• Do not adjust
by hand.
Horizontal airflow direction louver
• Manually adjustable.
• Be careful not to
insert your fingers
into the unit to
avoid injuring by
WARNING
cross-flow fan.
Remote
control
display
4
CS-UE12JKE
Receiver
INDICATOR
(GREEN) (ORANGE)
TO TURN ON OR OFF THE UNIT
• Please be aware of the OFF indication on the remote control
display to prevent the unit from starting / stopping improperly.
TO SET TEMPERATURE
• Selection range: 16˚C ~ 30˚C.
• Operating the unit within the recommended temperature could
induce energy saving.
HEAT mode : 20˚C ~ 24˚C.
COOL mode : 26˚C ~ 28˚C.
DRY mode : 1˚C ~ 2˚C lower than room temperature.
CS-UE9JKE
Auto OFF/ON button
• Used when remote control is misplaced or
malfunction.
Step Action
1 Press once.
Press and hold until 1 beep
2
is heard, then release.
Press and hold until you
3 hear double beep sound,
then release.
Press the button to turn off.
Mode
Auto
Force
Cooling
Force
Heating
