Movement EDGE SHOULDER Manual De Montagem página 69

ASSEMBLE
STEP 15 - PASSAGE OF THE ARMS' CABLES (CONTINUED)
20 NAME
Low profile hex nut
M8
26 NAME
Internal Hex. Cyl. Screw
M8X25
38 NAME
Label terminal
Tools
Tools
Allen 6 mm Fix Wrenche 13 mm
Sticker Thread lock
medium torque
QTY
2x
QTY
2x
QTY
2x
V
32
Figure 20-4
20
Figure 20-5
38
Figure 20-6
38
26
