Read all of Manual to become thoroughly familiar with this vehicle. Pay particular attention to all Notes, Cautions and Warnings
Thank you for purchasing this vehicle. Before driving the
vehicle, we ask you to spend some time reading this
Owner's Manual and Service Guide. This guide contains
the information that will assist you in maintaining this
highly reliable vehicle. Some illustrations may show
items that are optional for your vehicle. This guide covers
the operation of several vehicles; therefore, some picto-
rial views may not represent your vehicle. Physical differ-
ences in controls will be illustrated.
This vehicle has been designed and manufactured as a
'World Vehicle'. Some countries have individual require-
ments to comply with their specifications; therefore,
some sections may not apply in your country.
Most of the service procedures in this guide can be
accomplished using common automotive hand tools.
Contact your service representative on servicing the
vehicle in accordance with the Periodic Service Sched-
ule.
Service Parts Manuals and Technician's Repair and Ser-
vice Manuals are available from a local Distributor, an
authorized Branch or the Service Parts Department.
When ordering parts or requesting information for your
vehicle, provide vehicle model, serial number and manu-
facture code.

REFRESHMENT UNIT

The vending unit is equipped with two beverage compart-
ments, a cold storage compartment, a consumable ice
compartment, a food display cabinet, two cup dispensers
and a trash bin. Available accessories are listed in illus-
tration (Ref Fig. 1 on page 2).
Tool List
Ratchet, 3/8" drive....................................................... 1
Socket, 1/2", 3/8" drive................................................ 1
Wrench, 1/2" ............................................................... 1
Phillips screwdriver ..................................................... 1
Wrench, 7/16" ............................................................. 1
Drill .............................................................................. 1
Socket adapter, 1/4" drive ........................................... 1
Socket, 5/16", 1/4" drive.............................................. 1
OPERATION AND SERVICE INFORMATION
MOUNT VENDING UNIT TO REFRESHMENT
VEHICLE
The vending unit is heavy. Care and proper
lifting equipment and procedures must be
used when installing unit to reduce the pos-
sibility of severe injury and/or damage to
the unit. Be sure hands and fingers are clear
of unit while placing unit on frame.
The refreshment unit is shipped on a pallet. While resting
on pallet, the unit should be handled with a forklift. If a
forklift is not available, be sure an adequate number of
assistants are available to safely lift the vending unit.
Orient vending unit so that door on unit will be facing the
rear of the vehicle when unit is placed on the mounting
frame (Ref Fig. 1 on page 2). Using a forklift, lift the
refreshment unit and pallet level with the bed of refresh-
ment vehicle. Lift the refreshment unit off of the pallet and
carefully place it onto the mounting frame on vehicle.
Align the four mounting holes on refreshment unit with
corresponding holes on vehicle mounting frame. Secure
unit to frame with four 5/16 - 18 X 1 1/4" bolts (item 1),
eight 5/16" flat washers (item 2) and four 5/16 - 18 lock
nuts (item 3). Tighten hardware firmly.

FRONT STRUT INSTALLATION

Position front strut (item 4) and braces (item 5) as shown
(Ref Fig. 2 on page 3) and secure to vehicle at each side
of the cowl with four 5/16 - 18 X 2 1/2" bolts (item 6), four
5/16" lock washers (item 7), two spacers (item 8) and six
Qty. Required
3/8" flat washers (item 9). Secure top of braces with two
5/16 - 18 X 2 1/4" bolts (item 10), four 5/16" lock washers
(item 11) and two 5/16 - 18 lock nuts (item 12). Attach
canopy frame mounting plate (item 13) to front strut
using two 1/4 - 20 X 1 1/2" bolts (item 14), four 1/4" flat
washers (item 15) and two 1/4 - 20 lock nuts (item 16) as
shown. Tighten hardware firmly.

WINDSHIELD AND MIRROR INSTALLATION

Typical operation of a Refresher
Owner's Manual and Service Guide
®
vehicle on
