Once the front of the seat is lowered fully,
release the handle and push it forward to
ensure it has fully engaged on the front tube.
Rotate the safety locking pin so it engages in
front of the handle. If it hits the handle then
the seat is not inserted properly. Remove
and repeat process outlined above.
Always check the handle and locking pin
are fully engaged before you place the
child in the seating system. If the handle
is not engaged properly the seat unit can
come loose and could cause serious injury
to the child or carer.
7.3 Attaching the
push handle
The push handle is attached to the seatbase
by inserting the two lower stems into the
receiving tubes as shown. Secure the handle
in place by tightening the locking knobs (a).
Check these regularly to make sure the
knobs are tight, particularly if you are
moving the product unit along corridors
that may have uneven or sloping surfaces.
7.4 Attaching the
headrest
To attach the head support slide the stem
into the receiving bracket. Set to the desired
position and secure using the hand lever (a).
A
7.5 Attaching the
lateral supports
While holding the components together,
remove the screw and washer. Align the
plastic angle adjuster mouldings and lateral
bracket with the slot in the backrest and refit
the washer and plastic screw.
