AXIS T93F Series

Wall Mount

1
3
1
Network cable (route through wall bracket)
2
Power cable (route through wall bracket) (AXIS T93F10)
3
Screw T20 (4x)
4
Bracket adjustment screw T30
5
Wall bracket

LED Indicators (AXIS T93F10, AXIS T93F20)

LED Color
Status Green
Green, single flash
Green, double flash
Green, triple flash
4
5
Indication
Normal operation
Heater error
Self test
General error
