8.19 Foot support - angle
(Complex supports only)
To change the angle of the foot supports,
loosen the three screws (A) on the ball and
socket joint on the underside of the foot
support. Change the angle to suit the user's
requirements. Retighten the screws.
Note: A 5mm tool is required.
To flip away the foot supports, pull out the
pin (B) at the back of the sandals and rotate
it through 90°. Holding your thumb on C,
slide the foot support outwards, away from
C
the centre line, then flip up. The foot support
locks in the vertical position.
B
C
B
A
C
B
C
