Then, the screen will look like the following figure 4-6.
Figure 4-6: AC voltage Measurement
Making a DC Current Measurement
To measure a DC current which is less than 600 mA , do the following:
1) Press the A key and then DC appears at the screen. The unit on the main reading
screen is mA. Press F2 to switch the measurement between mA and 1OA. 6OOmA is
acquiescently.
2) Insert the black lead into the COM banana jack input and the red lead into the mA
banana jack input.
3) Connect the red and black leads to the measured points and the DC current value of
measured points will be displayed on the screen.
Then, the screen will look like the following figure 4-7.
To measure a DC current which is larger than 600 mA, do the following:
To measure a DC current which is larger than 600 mA, do the following:
1) Press the A key and then DC appears on the screen. The unit on the main reading
screen is mA.
2) Press F2 key to switch to I0A measurement, the unit on the main reading screen is A.
3) Insert the black lead into the COM banana jack input and the red lead into the
1OA
