INSTRUCTION MANUAL
Please read this instruction manual carefully
to obtain the best results.
CONNECTIONS TO MAIN SUPPLY
Make sure the supply voltage in your home is the
same as the voltage marked on the rating
plate of the appliance.
Warning: risk of fire, electric shock, physical injuries
and material damage.
Before using this appliance, always follow
the safety advice during assembly, use and
maintenance.
SAFETY INSTRUCTIONS
1. The heater should be hung on the wall and
the wind outlet should face down or be
placed on flat appliance. You must not place it
precipitantly or tipsily.
2. Please do not use the heater in places full of
combustible or explosive gas. Don't cover the
wind outlet.
3. If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person in order to
avoid a hazard
4. If nobody is in or you are repairing the heater,
please disconnect the heater from electric outlet.
5. Please don't touch the heater with wet hands
or other conductors.
6. Motor is out of order, please make it stop
immediately.
7. During use, please do not open the door or
window otherwise it will diminish the heating
effect.
8. To turn off the machine, press the on/off switch
to off, then the machine will keep the fan
working about 30 seconds until it blows out
cool wind, then the machine will stop working
and you can take out the plug.
9. Must hang the heater on the wall and fix it
away from water in bathroom.
10. Remote control, please use 1x CR2025 battery.
11. If the product needs repair, please ask experts
or our company authorized maintenance
department.
12. This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
13. Children should be supervised to ensure that
they do not play with the appliance.
14. Cleaning and user maintenance shall not be
made by children without supervision.
15. Children of less than 3 years should be kept
away unless continuously supervised.
16. Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed
in its intended normal operating position and
they have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance or
perform user maintenance.
17. CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
18. CAUTION: In order to avoid a hazard due to
inadvertent resetting of the thermal cutout,
this appliance must not be supplied through
an external switching device, such as a timer, or
connected to a circuit that is regularly switched
on and off by the utility.
19. WARNING: In order to avoid overheating, do not
cover the heater.
20. The heater must not be located immediately
below a socket-outlet.
21. Means for disconnection having a contact
separation in all poles must be incorporated in
the fixed wiring in accordance with the wiring
rules.
22. The heater must be installed at least 1.8m
above the floor.
23. Do not use this heater in the immediate
surroundings of a bath, a shower or swimming
pool.
WARNING:
Don't touch the working machine and don't
cover the wind outlet and inlet!
INSTALLATION
(see picture A):
Drill two holes into the wall and keep a distance
of 1.8m from the ground. The diameter of the hole
just contains the inflated plastic pipe. After tucking
the inflated plastic pipe, fix pothook on the pipe
with screws. Make sure pothook are safely placed
and hang the heater. The clip under the pothook
should be inserted rabbet of the heater bottom.
2
FUNCTION OPERATION
(both machine & remote control)
1. Plug in and switch on by pressing the red
switch 0/I, enter into standby mode and display
shows " ":
2. Press " " button enter into fan mode, see
below:
3. Press " " button for one time, the product
works with low heating and display show " -- /
I ", see below: A. Press second time, changes to
high heating and display show " -- / I / II ", see
below: B.
4. Press " " button to set timer (00-12hours).
Pressing the button one time increases one
hour for timer. After setting time, the display
will show current setting time for 5 seconds,
then resume to previous display, meanwhile
the light of " " will on. Below photo (C) is an
example of setting 8h:
A B C
5. Appointment "ON": In standby mode, press "
" timer button, you can set the appointment
turn-on time in 00-12 hours. After complete
setting, the display shows the appointment
turn-on time and also the light " " is on. The
display automatically decreases 1 hour for each
hour passed. When the appointment power-on
time arrived, the product will automatically
turns on. The default setting temperature
is 23°C during appointment turn-on. Below
photos is an example to set appointment turn-
on time to 8 hours:
Note: If not setting the temperature and weekly
program, the product will automatically turn-off
after 12 hours of continuous work, and enter into
standby.
FUNCTION OPERATION
(ONLY by remote control)
1. Set current TIME/DAY (can set both under
standby mode & working status):
Press "SET" button for one time, the display
shows "12" as default, press "+/−" to set current
hour (total in 24 hours); press "SET" again, the
display shows minute "30", press "+/−" to set
current minute (00~59 minutes), then press
"SET" for third time, the display shows the day
"d7", press "+/−" to set current day (Monday-
Sunday: d1-d7). Then press "OK" to confirm the
setting, the display will show previous settings.
For example: Setting to Wednesday, 9:30 AM
under 25°C under II heating, pls. refer to the
following photos:
Note:
- If main switch off, power cut off, or plug out, it
need reset.
- Press "SET" to check the current time & day in
turn;
2. Set temperature
During working status, press "+/−", the display
shows "23" as default. Press "+/−" to set desired
temperature (temperature range 10-49°C),
press "OK" to confirm the setting.
For example: The current ambient temperature
is 15°C, when set temperature to 25°C, the
display shows as below:
Note:
When setting temperature, it will use SMART
working way:
1) Setting temperature – ambient temperature
>2°C, working with high power;
2) 0°C <Setting temperature – ambient
temperature =<2°C, working with low power;
3) Setting temperature – ambient temperature
=0°C, the cool fan will work for 30 seconds to
below out the heating left inside, then enter
into standby mode.
4) after enter into standby mode, if the machine
cool down and:
Setting temperature – ambient temperature
>=2°C, the machine will wake up and resume to
heating.
3
