EN
Clean the external borders
NOTE:
of the inside of the blade before
reassembling. Put a drop of oil on
the inner and outer edge touching
the blade. Mount the new blade on
the shaft. Place the outer edge (K)
and tighten the blade bolt (D).
The direction in
ATTENTION:
which the blade rotates has to be the
same as the arrow indicated on the
machine frame.
Before using the saw again, make sure
the safety devices are working properly.
After replacing the
IMPORTANT:
saw blade, make sure that it rotates
freely by turning it by hand. Connect
the machine to the mains and put
it to spin without material to check
if it turns smoothly, before using it
to cut.
USE PARALLEL GUIDE
The parallel guide (G) allows you
to make parallel cuts in a piece of
wood, all with the same width.
Release the button (H). Slide the
parallel fence (G) in the notches of
the lower plate. Adjust the parallel
slit to the desired width and hold it
in position with the button (G).
Make sure the parallel slit is
NOTE:
leaning against the wood along the
entire length allowing a parallel and
consistent cut.
OPENING THE BLADE
PROTECTION
The blade guard extends automatically
being pulled by wood cutting. To open
it manually, use the lever (I).
POWDER EXTRACTION
The circular saw is equipped with a
hole for dust extraction.
MAINTENANCE
Make sure the
WARNING:
machine is off the button and
off the power before performing
any maintenance or adjustment
procedure. Always wear sturdy
gloves when moving or replacing
blades.
Keep unimpeded respirator and
clean it after each use. Check
regularly if any residue entered
the grid engine or trigger that
disrupts the normal operation of
the machine. Use a soft brush to
remove grit. Wear eye protection
while cleaning the machine.
Lubricate all moving parts at regular
intervals. If the saw body needs to
be clean, use a damp, soft cloth. It
can be also used a mild detergent,
but nothing with alcohol, gasoline
or other cleaning agent. Never use
abrasives to clean the plastic parts.
: The water should never
CAUTION
come in contact with the saw.
OVERVIEW
Periodically check if the
mounting screws are tightened.
If the connecting cable needs
replacement, the task should be
carried out by a qualified technician
in order to avoid possible dangers.
DECLARATION OF
CONFORMITY
We declare under our exclusive
responsibility, that the product Meets
the following standards
or standardization documents:
EN 60745-1,EN 60745-2,
EN 55014-1, EN 55014-2,
EN 61000-3-2 and EN 61000-3-
3, according to the determinations of
the directives:
2004/108/CE - Electromagnetic
Compatibility Directive;
2006/42/CE - Machinery Directive;
2006/95/CE - Low Voltage Directive;
2000/14/CE - Sound power level
guaranteed: 98 dB.
WARRANTY TERMS
The warranty of this machine is two
years from the date of purchase.
You should, therefore, keep your
proof of purchase during this period
of time. The warranty covers any
manufacturing defect in material or
operating, as well as parts and work
needed for their recovery. Excluded
from the warranty the misuse of
the product, any repairs carried out
by unauthorized persons (outside
the service center of the brand
ITOOLS) as well as any damage
caused by the use of it.
