Creative PEBBLE V3 Quick Start Guide página 2

1. Overview
FRONT VIEW
L
c
LED Indicator
USB Audio mode:
High Gain
Low Gain
Note: High Gain / Low Gain Switch is
located under the right speaker. Refer to
g illustration
AUX-in mode:
Detected / Connected
d
Volume Knob
Disclaimer: If Pebble V3's volume remains low when both
device and speakers are at maxed volume while connected
to a laptop's USB port, connect the speakers to a 10W USB
port instead to achieve optimum volume level
REAR VIEW
L
R
Solid Blue
Solid Green
Solid Cyan
Off / Vol – Vol + / Max
R
a
2.25" Full-range Drivers
b
Bluetooth / Source Button
®
i) Bluetooth Pairing mode / LED Indicators:
2s
Select "Pebble V3" from the list of
discovered Bluetooth devices on your
mobile device to pair. Upon successful
pairing, LED will pulse in blue.
High Gain mode:
Bluetooth Paired / Connected
Bluetooth Pairing mode
Low Gain mode:
Bluetooth Paired / Connected
Bluetooth Pairing mode
ii) Toggling Between Sources:
x1
USB Audio
When AUX-in cable is detected / connected
*
Note: When plugged into a PC / Mac for the first time,
Creative Pebble V3 will be in USB Audio mode by default.
When plugged into a power source that does not support
USB Audio for the first time, Creative Pebble V3 will be in
Bluetooth Pairing mode by default
e
Passive Radiators
f
AUX-in Port
g
High Gain / Low Gain Switch
Pulsing Blue
Flashing Blue
Pulsing Green
Flashing Green
Bluetooth
AUX-in
*
