Preparation

Wear the safety goggles to avoid injuring your

eyes while assembling the components.

1. Preparing the Gel Beads

Refer to the label on the bottle for

more information on how to soak

the gel beads properly before

assembly.

2. Charging the Battery

Charge the battery to bring it out of hibernation

before using for the first time.

Charging Time: Approx. 1 hour and 30 min.

3. Preparing the Screwdriver

The package includes a screwdriver handle and two

bits. The #1 bit is used with screw box A. The smaller

end is for T2 screws, while the larger end is for the

other screws in screw box A. The #2 bit is used with

screw box B. The smaller end is for all the screws in

screw box B, while the larger end is not used. Make

sure to use the screws with a suitable bit.

4. Legend

(M3-A)

100-240 V

50-60 Hz

5. Cable Connection Instructions

Connect the black, orange, and red cables to the

ports with the corresponding color.

Follow the instructions for cable connection and

wiring to avoid cable damage.

Refers to the accessories required

including such information as the

screw model and quantity. For

×6

example, the description in this

illustration indicates that six screws

of the M3-A model are required.

Indicates that the bottom of the

robot is displayed.

Refers to where the required

accessories are located in the screw

box.
