2.11 Inspection window assembly

2.11.1 Components

7
6
5
1 = Wiper
2 = Flange
3 = Nut
4 = Protective cap

2.11.2 Position

The inspection window unit can be
positioned to the
of the centre axis of the tank.
Assembly on the right
below.
LipuJet - P -RB / - RD / - RM / - RA / - RAP
5 = Plexiglas
6 = Sealing
7 = Stud bolts
right or left
described
Installation
1
2
3
4
