HVAC control
On/Off. Pressing the icon turns the zone in which the thermostat is located on or off.
23.5° Set-point temperature. You can select the desired setpoint temperature in steps of 0.5 °C.
Slide to adjust the temperature with a larger interval.
Allowed ranges are:
EN
>
In heat mode: 15-30 ºC
>
In cool mode: 18-30 ºC
Operation mode
This is managed from the master thermostat, press to access the selection menu. The available
modes are as follows:
Cooling. In this operation mode, the system only operates with the AC unit in cooling mode
when any of the zones associated to the system is generating demand (set-point temp. <
room temp.).
Heating. In this operation mode, the system only operates with the AC unit in heating mode
when any of the zones associated to the system is generating demand (set-point temp. >
room temp.).
Ventilation. In this operation mode, the system only operates with the AC unit in ventilation
mode when any of the zones associated to the system is generating demand.
Fan speed
The default setting is Automatic mode, imposing airflow based on the number of zones on
demand. Depending on the type of installation, it will be possible to select the speed manually
from the master thermostat.
High speed
Medium speed
Zone settings
Press on the icons to access the parameters:
Anti-freezing. Prevents the room temperature in the zone from dropping below 12°C, even
if the zone is off. (In Stop mode it will not be activated).
Timer. (only available on Airzone Cloud) The selectable values are:
Off. The timer is off.
30. Activates the timer and after 30 minutes, the zone is switched off.
60. Activates the timer. 60 minutes after activation, the zone switches off.
90. Activates the timer. 90 minutes after activation, the zone switches off.
22
Low speed
Automatic speed
