9 | Configuration and operation
Country- Me- Display/
spec. Set- nu Setting
tings level
1. punto de apoyo ...
1 2 3 4 4
10. punto de apoyo
Voltage | Reactive
power | Excitation
0 - max. voltage in
continuous operation
[V] / 207 [V] /
[V]
0-100 [% S
43.6 [%] /
Over-excited | un-
der-excited
Det. isla ampl.
1 2 3 4 4
BE CH-NS Error de la red
1 2 3 4 4
CY DE-NS
DK JP-50HZ
JP-60HZ
LU-NS TW
UD
Advanced features
1 2 3 4 4
Información
1 2 4
3
Tipo inversor
1 2 3 4 4
Versión SW
1 2 4 4
3
N° serie
1 2 3 4 4
Vis. país
1 2 3 4 4
Fabricante
1 2 3 4 4
9.4.2

Configuration via web user interface

AVISO
In addition to the parameters in the chapter [Ver capítulo 9.4.1} Página 37], additional parameters are availa-
ble and accessible via the web user interface. To do so, enable Remote config in Network under Web-
server and enter the device IP address into your browser.
Operating settings
1 2 3 4 4
CC Tensión inicial
1 2 3 4 4
/ [Ver capítu-
lo 4} Página 12] / [
[V]
Reg. tensión const.
2
1 3 4 4
/ [Ver capítu-
lo 4} Página 12] [V] /
1 [V]
Página 48
Action in this menu/meaning
F Enter the voltage of the node in volts.
1
] / F Set the reactive power of the node as a percentage of the maximum
max
0.1 power.
F If a reactive power not equal to 1 is selected: Select the type of pha-
se shift.
AVISO: Grid operators require shutdown of the device with
standalone grid detection.
F Further parameterisation is possible via the web interface.
AVISO: Display of grid faults.
F To show the last 5 grid fault messages, press the Show button.
F Further parameterisation is possible via the web interface
Open the menu: Press the right arrow button or the OK button.
Displays the type designation of the device. If feed-in power is actively
limited: display maximum power in kW.
Displays the installed software version.
Displays the serial number of the device.
Displays the selected country setting. Optional: Displays the grid type if
a grid type has been selected.
The display shows information about the device manufacturer.
AVISO: Options for advanced setting of the operating parame-
ters.
The device begins feed-in as soon as this DC voltage is present.
F Set the starting voltage.
1
AVISO: Option to disable the MPP seek mode in order to ope-
rate the device with a constant DC voltage.
1. Activate or disable the constant voltage controller.
2. Set value for constant voltage controller.
Manual
Kaco blueplanet 29.0TL3
