Conexión Tri-Clamp Según Din 32676, Serie A - Jumo Flowtrans Mag H20 Manual Breve

4 Datos Técnicos
4.7.2 Conexión Tri-clamp según DIN 32676, serie A
Diámetro Ø Di [mm]
nominal
DN 6 6,0
DN 15 12,5
DN 20 15,0
DN 25 26,0
14
Di
Ø
Ø D [mm] A [mm]
25,0
34,0
79
34,0
50,5
flowTRANS MAG H20
B [mm] C [mm]
53 51
L
A
L [mm] H [mm]
110
130
73
