STEP 2: REMOVE OLD FILL VALVE
A: REMOVE CONNECTOR
Remove water supply
connector from bottom
of fill valve by twisting
connector nut to the left.
Towel
(Optional)
B: REMOVE OLD LOCKNUT
Below tank, twist locknut
to the left to remove from
fill valve.
C: REMOVE OLD FILL VALVE
Including refill tube, refill
clip and shank washer.
Drain any excess water
into bucket by removing
fill valve from tank.
(Pull fill valve up)
Bucket
(Optional)
4
NOTE: Inspect water
supply connector.
Replace it if it is worn, or
you don't know how old it
is, to prevent flooding and
property damage.
