Scaffolding technical specifications
Chapter 1:

1-1. Marking

EN 1004 3 8M/12M XXXD H2
Reference
standard

1-2. Technical specifications

Construction:
Mobile scaffold category III EN 1004-1
Welded aluminium structure
Overall dimensions without stabilisers:
NEOLIUM LINE
Length (m)
Width (m)
Load structure:
• Point load: 150 Kg on a single loaded platform
• Maximum allowable load on a single level: 200 Kg/m² uniformly distributed on the platform.
This means a uniformly distributed load of 250 kg for the NEOLIUM LINE 200, 319 kg for the
NEOLIUM LINE 250, and 385 kg for the NEOLIUM LINE 300, 500 kg for the NEOLIUM 400 and
770 kg for the NEOLIUM 600.
• 1 person per platform
Only the last platform should have a person on it, provided the load limits detailed above are
respected.
106-A000035565 - ind.D - 11/2021
Load
Maximum height for indoor /
category
exterior use
200
250
2.2
2.7
0.93
0.93
access by stairs: no
access by steps: no
access by inclined ladder: no
access by vertical ladder: yes
Height between platforms
H1: 1.85 m
H2: 1.9 m
300
400
600
3.2
2.2
3.2
0.93
1.68
1.68
49
