Technical parameters

Voltage range:
Minimum consumption
(idle mode):
Maximum power consumption
(pulses 100Hz):
Working temperature:
Sensor LS responds only to light pulses, i.e. it does not detect static state LEDs.
Voltage range:
Consumption:
Output load:
Scanning period:
Switch sensing sensitivity
(output L):
Opening detection sensitivity
(output-> H):
Hysteresis:
Working temperature:
Voltage range:
Consumption:
Output load:
Switch sensing sensitivity:
Opening detection sensitivity:
Hysteresis:
Working temperature:
Common data
Cross-section of connecting wires:
Wire length:
Protection:
* Measured at 3V, no load output.
Warning
Instruction manual is designated for mounting and also for user of the device. It is always
a part of its packing. Installation and connection can be carried out only by a person
with adequate professional qualifi cation upon understanding this instruction manual
and functions of the device, and while observing all valid regulations. Trouble-free
function of the device also depends on transportation, storing and handling. In case
you notice any sign of damage, deformation, malfunction or missing part, do not install
this device and return it to its seller. It is necessary to treat this product and its parts
as electronic waste after its lifetime is terminated. Before starting installation, make
sure that all wires, connected parts or terminals are de-energized. While mounting and
servicing observe safety regulations, norms, directives and professional, and export
regulations for working with electrical devices. Do not touch parts of the device that are
energized - life threat. Due to transmissivity of RF signal, observe correct location of RF
components in a building where the installation is taking place. RF Control is designated
only for mounting in interiors. The must not be installed into metal switchboards and
into plastic switchboards with metal door - transmissivity of RF signal is then impossible.
RF Control is not recommended for pulleys etc. - radiofrequency signal can be shielded
by an obstruction, interfered, battery of the transceiver can get fl at etc. and thus disable
remote control.
LS
2.5 .. 3.7V
0.5uA *
max. 2uA *
-20 .. 50 °C
MS
1.6 .. 3.6V
7uA *
max. 3mA
100ms
±(2.3 .. 4.7)mT
±(0.9 .. 3.8)mT
1mT
-40 .. 80 °C
WS
1.65 .. 5.5V
1.5uA *
max. 150uA
±(0.3 .. 1.1)mT
±(0.2 .. 0.9)mT
0.2mT
-40 .. 80 °C
max. 3.5 mm
1.5 m
IP20
2 / 2
Connection to RFTM-1
LS / MS / WS
+
5
4 6
3 7
2 8
9
1
SENZOR SET
3V3
DATA1
-
DATA2
GND
RFTM-1
0 0 0 0 0 , 0 0
Output S0
+
5
4 6
3 7
2 8
1 9
SENZOR SET
3V3
+
DATA1
-
DATA2
GND
RFTM-1
1. Brown wire
2. Green wire
3. White wire
1
2
3
0 0 0 0 0 , 0 0
S0
+
