Technical specifications

Rasther Android
Minimum mobile device configuration:
• Access to the Internet;
• Android 3.0 or higher;
• Bluetooth.
Rasther PC
Minimum Computer Configuration:
• Celeron Dual Core 2.6 GHz;
• 2 GB ram;
• HD 40 GB;
• 1024 x 768 pixel display;
• Internet access;
• Mouse and keyboard;
• Bluetooth 2.0 compatible or external adapter (recommended USB Bluetooth
CSR8510);
• Supported operating systems: (32/64 bits), Windows 7, Windows 8 / 8.1,
windows 10.
TM537 Rasther Box Shock
• Supply voltage: 10 to 28 Vdc;
• Operating current: 180 mA;
• Charging current: 800 mA max.
• Battery: Li-PO 7.4V 1400mA / h;
• Dimensions (mm): 50/170/130 (W / L / D);
• Weight: 490g (Rasther Box Shock without accessories).
Bluetooth
• Bluetooth: 2.0 + EDR, Class 1;
• Carrier frequency: 2400 MHz to 2483.5 MHz;
• Modulation: GFSK / EDR;
• Transmit Power: -6dBm to +20 dBm;
• Receiving Sensitivity: -88dBm to -20dBm;
• Antenna: integrated chip-antenna type.
Chip-Antenna Specification
• Central frequency: 2450 ± 25 MHz;
• Bandwidth: >150MHz;
• Gain: 1.5 dBi Typical;
• Polarization: Linear;
• Azimute: Omni-directional;
• Impedance: 50 Ohms.
