External Circulation - Thermo Scientific Arctic Serie Manual De Instrucciones

Circulation
CAUTION
Thermo Scientific
External
The plumbing connections for external circulation are located on the
rear of the immersion circulator.
external application.
(supply side). The connections are 16 mm O.D. Remove the union nuts
and plates to install the 8 mm or 12 mm hose barbs and clamps supplied
with the circulator.
USB Port
AC 200 only
(see next page)
RJ45 (only used
with refrigerated
baths)
Insulation - Used
for G50 Low Temp
Operation only
Outlet Flow
Note G50 circulators are supplied with 1
tion (4 total). For low-temperature operation, install a single piece of
insulation on each of the pump lines.
To prevent damage to the circulator's plumbing, use a 19 mm
backing wrench when removing/installing the connections.
is the return flow from the
is the outlet flow to the external application
Connections (Typical)
/ " (32 mm) pieces of insula-
1
4

Section 3 Installation
Remote Temperature
Sensor (see next page)
Multifunction Port
AC 200 only
(see next page)
Return Flow

3-7
