65E10 Hook-Up Diagram; 65E10 Reversing Hook-Up Diagram - DART Controls CONTROL Serie Manual Del Usuario

Min Speed
Max Speed
Accel
I.R. Comp.
Current Limit
Min Speed
Max Speed
Accel
I.R. Comp.
Current Limit
Caution: When reversing a spinning motor, caution must be taken that the resulting current through the
armature of the motor does not exceed the overload ratings of the control, or the demagnetize rating of
the motor being reversed when using a permanent magnet DC motor.

65E10 HOOK-UP DIAGRAM

Inhibit (P1-9)
Common (P1-8)
Pot Low (P1-7)
Pot Wiper (P1-6)
Pot High (P1-5)
-Arm (P1-4)
+Arm (P1-3)
+Battery (P1-2)
-Battery (P1-1)

65E10 REVERSING HOOK-UP DIAGRAM

P1
Inhibit (P1-9)
Common (P1-8)
Pot Low (P1-7)
Pot Wiper (P1-6)
Pot High (P1-5)
-Arm (P1-4)
+Arm (P1-3)
+Battery (P1-2)
-Battery (P1-1)
Optional
Inhibit
(see hook-up
below)
P1
Orange
Red
White
Battery
Customer supplied
SPST switch or relay
Optional
Inhibit
(see hook-up
below)
5KW
Speedpot
Orange
Red
White
Battery
Customer supplied
SPST switch or relay
3
5KW
Speedpot
Motor
Customer supplied
3PDT Center-off
Center-blocked switch
Motor
