24
Figure 11-2
The small white dials control the time interval
Top White Dial
used on the main larger blue dials. Each white
(ON time)
dial controls the corresponding blue dial.
Based on the intermediate value setting on the
white dial, the blue dial can be set at any
specific value required.
Top Blue Dial
(ON time)
•
•
Bottom White Dial
(OFF time)
Bottom Blue Dial For example: for 2 minutes ON and 4 hours
(OFF time)
OFF, you would use the following settings:
–
–
–
–
The top white and blue dials control the
length of time the agitation stays ON
(duration)
The bottom white and blue dials control
the time the agitation stays OFF
(pause between agitations)
Top white dial set to "1-10"
Top blue dial set to "2"
Bottom white dial set to "1-10h"
Bottom blue dial set to "4"
COROB™ D50
