Technical data

Type of machine:
Complete machine
Technical data:
BBF10
Electrical connection:
Electrical rating:
Electrical connector:
Mains cable:
Fusing:
Pneumatic connection:
Inlet filling medium:
Filling performance for individual bags:
Weight:
Length x width x height:
BBF14
Electrical connection:
Electrical rating:
Electrical connector:
Mains cable:
Fusing:
Pneumatic connection:
Inlet filling medium:
Filling performance for individual bags:
Filling performance for bags off the roll:
Weight:
Length x width x height:
Prescribed environmental conditions:
The ambient temperatures must be between 0°C and 50°C for operation, storage and transport.
The machine should be placed on a flat, stable flooring with the respective weight carrying
capacity (see Technical Data).
Translation of the original operating instructions Bag-in-Box Filler BBF10 & BBF14
10.07.2017
3 phase / N / PE 400 V AC 50 Hz
2.5 kW
male CEE 5 pole 16 A
approx. 5 m
16 A
6 bar
NW 25
approx. 280 x 3 l/h, 220 x 5 l/h, 150 x 10 l/h
approx. 210 kg
1100 mm x 900 mm x 1600 mm
3 phase / N / PE 400 V AC 50 Hz
2.5 kW
male CEE 5 pole 16 A
approx. 5 m
16 A
6 bar
NW 25
approx. 280 x 3 l/h, 220 x 5 l/h, 150 x 10 l/h
approx. 330 x 3 l/h, 280 x 5 l/h, 250 x 10 l/h
approx. 210 kg
1100 mm x 900 mm x 1600 mm
