Technical Data; Standard Accessories; Manufacturer - Sonel TKF-13 Manual De Uso

a) Type of insulation in accordance with EN 61010-1 ................................................................. double
b) Measurement category in accordance with EN 61010-1 ..................................................... III 600 V
c) Ingress protection in accordance with EN 60529 .................................................................... IP42
d) Frequency range .............................................................................................................. 2 ÷ 70 Hz
e) Nominal phase-to-phase voltage range .................................................................. 127 ÷ 690 V AC
Phase-to-phase working voltage range ................................................................... 120 ÷ 760 V AC
f)
g) Motor voltage range .................................................................................................... 1 ÷ 760 V AC
h) Measurement current (per each phase) .............................................................................. <3.5 mA
Working temperature ...................................................................................................... -10 ÷ 45ºC
i)
Storage temperature ....................................................................................................... -20 ÷ 60ºC
j)
k) Battery charge diode blinking rate ......................................................................... approximately 1 s
l) Time before automatic turn-off .......................................................................... approximately 5 min
m) Tester power supply ............................................................................. alkaline battery 6LR61 (9 V)
n) Dimensions .......................................................................................................... 130 x 72 x 31 mm
o) Mass of the tester (with battery, without leads) .................................................................. ca. 150 g
The device does not have the character of a standard and therefore is not subject to
calibration. The proper form of control for this type of instrument is checking.
The standard set of equipment supplied by the manufacturer includes:

1.2 m test leads (red, black and yellow) – 3 pcs,

crocodile clip black K01,

probe with banana plug (red, black and yellow) – 3 pcs,

battery 9V – 1 pcs,

user manual.
The current list of accessories can be found on the manufacturer's website.
The manufacturer of the device and provider of guarantee and post-guarantee service:
NOTE!
Service repairs must be performed only by the manufacturer.
12

11 Technical data

12 Standard accessories

13 Manufacturer

SONEL S.A.
Wokulskiego 11
58-100 Świdnica
Poland
tel. +48 74 858 38 60
fax +48 74 858 38 09
E-mail: export@sonel.pl
Web page:
TKF-13 – USER MANUAL
www.sonel.pl
