GENERAL DESCRIPTION

Fig. 1 Plug-in receiver FOX SR
Fig. 2 Mini receiver FOX RB
Fig. 3 Modular receiver FOX R4
Fig. 4 Transmitters FOX 2 and FOX 4
Fig. 5 Radio control opening FOX
1. Connector for external connections
1-2 Power supply
3-4 Relay 1 output
5-6 Relay 2 output
7-8 Relay 3 output
9-10 Relay 4 output
11-12 Antenna
2. Jumper for power supply selection
3. Storage
5. Button P1 and LED L1
6. Button P2 and LED L2
7. Button P3 and LED L3
8. Button P4 and LED L4
9. Connectors for inserting relay modules.
10. Antenna connector
