Safety Notes

Gloves should be worn during installation to prevent

crushing and cutting injuries.
The shower system may only be used for bathing,

hygienic and body cleansing purposes.
The hot and cold supplies must be of equal pres-

sures.
Do not allow the streams of the shower touch sen-

sitive body parts (such as your eyes). An adequate
distance must be kept between the shower and you.
The product may not be used as a holding handle. A

separate handle must be installed.

Installation Instructions

The fitting must be installed, flushed and tested after the
valid norms.

Technical Data

Operating pressure:
Recommended operating pressure:
Test pressure:
(1 MPa = 10 bar = 147 PSI)
Hot water temperature:
Recommended hot water temp.:
anti-pollution function

English
Symbol description
max. 1 MPa
0,1 – 0,5 MPa
1,6 MPa
max. 80°C
65°C
Assembly see page 31
Maintenance non return valve
(see page 39)
The non return valves must be checked
regularly according to DIN EN 1717 in
accordance with national or regional
regulations (at least once a year).
Maintenance Secuflex hose (see
page 39)
Repeat cleaning when pull out becomes
difficult.
Do not use silicone containing acetic acid!
Dimensions (see page 37)

Flow diagram

(see page 37)

Hand shower

Bath Spout
Spare parts (see page 42)
Operation (see page 38)
Cleaning recommendations,
see enclosed brochure.
