Technical Specifications - Atlantis Volta Pro Quick Start Guide

TECHNICAL SPECIFICATIONS

1/2.8" color CMOS
Image Sensor
Lens M12, f: 3.5mm, F2.0, 3-Megapixel
Visual angle 120° (field of view)
Minimum Illumination 0.01 Lux
Video Compressing H.264
Image Frame Rate 15 fps
2304x1296
Maximum Resolution
IRCUT double optical filter
IR LED
automatic switching, and 8 infrared
lights (850nm wavelength)
Irradiation distance 5 meter
Audio Two-way voice intercom available
(built-in Microphone and speaker)
Wireless Network 2.4GHz Wi-Fi (IEEE802.11b/g/n)
built-in antenna
TCP/IP, UDP/IP, DHCP, RTMP, MUTP
Protocols Supported
IP Address Supported Dynamic IP address supported
Features - Human contour detection
- Activity zone
(Subscription fee required)
- Intelligent push
- Pet snapshot
- Package inspection
Alarm push by mobile APP and
Alarm Methods
alarm sound
Local Alarm White light flashing and alarm
sound warning (Siren)
Wake-up Method PIR body induction wake-up and
remote positive wake-up
Recording Method Alarm triggered recording and
manual recording
Cloud storage, local Micro SD card
Video Storage
and mobile phone memory
LED Indicator RGB tri-color lamp indicating the
status of power, network signal,
functionality
Battery Type Rechargeable Li-Ion Battery
(2 x INR18650-2200A)
Battery Capacity 3,7V / 4,4Ah (16,28Wh)
~ 240 minutes (with 1,0A)
Charging time
5,0VDC ± 5% / 1,0A
Charging Voltage
(Type-C interface)
Waterproof IP65
Slot Card 1 Micro SD card (up to 128GB)
not included
Size (LxWxH) 67x58x89 mm (without bracket)
