Hardware Identifi cation

å
Screws are shown actual size. You may receive extra hardware with your unit.
F12
HIDDEN CAM - 16
CROSS SLOTTED
F31
DOWEL - 28
S80 3" HEX HEAD SCREW - 28
Page 2
Assembly Tools Required
2
3
4
5-17
18-19
20-21
22
23
F13
CAM SCREW - 16
M30
L-WRENCH - 1
www.sauder.com/service
No. 2 Phillips Screwdriver
Tip Shown Actual Size
F14
WOOD DOWEL - 6
P38 APPLIQUE CARD - 3
S81
1/2" MACHINE SCREW - 4
436616
