Texecom Premier Elite IR Instruction Manual

1
E N E S F R I T N L P L P T S V D E
Instruction Manual
Premier Elite IR
Prestige DT/CW Only
<1m
Prestige DT/CW Only
MADE IN ENGLAND INS543-2
6 - Premier Elite IR
8
JP4 - ALARM
JP3 - TAMPER
JP3 - TAMPER
8.1
Panel
Support
8.2
Alarm EOL
Tamper
EOL
2 3
2
<1m
1
JP1
JP2 PULSE COUNT
0.3 - 3.0m/s
1 - 10ft/s
Mounting Height
9
Top View
Metres
15m
Metres
12m
15m
JP4 - ALARM
12m
Side View
Texecom Cooper Honeywell DSC
Menvier
4K7 4K7 1K 5K6
2K2 2K2 1K 5K6
4
✗
✓
✗
✓
7
2m
6'7"
2m
6'7"
2m
6'7"
2m
6'7"
10
CEILING MOUNT BRACKET
1 2 3
85°
12m
WALL MOUNT BRACKET
1 2 3
12m
4 5
Seal all holes
5
15m
Product description
The Premier Elite IR is designed to detect movement of an intruder and
50'
activate an alarm control panel. The product is intended to be connected to
a listed burglar compatible control unit or a power supply that has a voltage
output range of between 9 to 15 VDC and provides a minimum of 4 hours of
standby power.
✓
1. Installation guidelines
!
The technology used in these detectors resists false alarm hazards. However,
avoid potential causes of instability such as (see Fig. 1).
2. Opening the detector
• Unwind the screw at the base of the detector until loose; the screw will be
• Lift detector lid out from the base and off the lugs at the top (see Fig. 2, step
3. Detector knockouts
4. Mounting the detector
5. Coverage & pick-up
!
6. Premier Elite IR set-up
• Set the mounting height by adjusting the position of the PCB.
• Wire the detector.
• Select the desired jumper settings.
15m
7. Altering Coverage (at 2m Mounting height)
50'
8. End of Line Jumper links
•
✓
• JP3: Selects the End-of-Line resistance. Equivalent to wiring a resistor of
• JP4: Selects the resistance across the alarm relay. Equivalent to wiring a
• If EOL wiring is not used, the headers should be left in the default (O/C)
• If the required resistance values are not available, leave the headers in the
8.1. Double Pole (jumper links not used)
8.2. Dual End-of-Line (DEOL)
9. Coverage Pattern
10. Bracket installation (Brackets available separately, Part No. AFU-
0004-2)
Regulatory information
Supplier: Texecom Ltd, St. Crispin Way, Haslingden, Lancashire, BB4 4PW, UK.
Weee Directive: 2002/96/EC (WEEE directive): Products marked with this
RoHs Directive: 2002/95/EC RoHS Compliant. Hereby, Texecom declares that
this device does not contain lead, mercury, cadmium, hexavalent chromium,
polybrominated biphenyls (PBB) or polybrominated depheny ethers (PBDE)
in more than the percentage specified by EU directive 2002/95/EC, except
exemptions stated in EU
8m
directive 2002/95/EC annex.
26'2" CE Directive: 2004/108/EC (CE directive): Hereby, Texecom declares that this
Maintenance: Test yearly by the installer
Warranty: 10 year replacement warranty
Security grade: EN Grade 2
Environmental class: Class II
10m Standards: EN50131-2-2
The Premier Elite IR is not a complete alarm system, but only its part. Therefore
32'9"
Texecom does not accept any responsibility or liability for any damage that
is claimed to be a result of an incorrect functioning of the Premier Elite IR
detector. Texecom reserves the right to change the specification without a
prior notice.
15m
50'
15m
50'
Specifications
Product Type Elite IR - AFD0000
Detector PIR
Signal processing Analogue
Range 15 m
Optical Fresnel Lens
Input power 9V to 15V (15 V nominal @ 10.6 mA)
DC DC DC
Detector start-up time 60 seconds
Normal current 12.9
consumption (mA)
Current consumption 15.2
in Alarm (mA)
Max current 15.2
consumption (mA)
Remote LED 12V 0V/NC
Mounting height Min. 1.5 m (4.1 ft), Max. 3.1 m (10 ft.)
Target speed range 30 cm/s to 3 m/s (1 ft/s to 10 ft/s)
Alarm relay < 24V 50 mA (N/C) 10 Ω
DC
Tamper relay < 24V 50 mA (N/C)
DC
Alarm time > 2 seconds
Operating -10˚C to +55˚C (14˚F to 130˚F)
temperature
Dimensions (HxWxD) 112mm x 60mm x 40mm
Relative humidity Max. 95%
Weight 150g
Power supply Rated 94HB
Contact information: www.texe.com
Cer tificate Number: FM 35285
The Premier Elite detectors are protected by UK & International Registered
Designs. Registered Design No's: 3004997, 3004260 & 3004261.
Premier Elite is a Trademark of Texecom Ltd. © 2011 Texecom Ltd.
EN: Installation Sheet
retained in the product (see Fig. 2, step1).
2).
The jumper links JP3 and JP4 are used to select resistances for End-of-Line
(EOL) wiring applications.
the selected value as shown.
resistor of the selected value as shown.
position.
O/C position and wire in external resistors as normal.
symbol cannot be disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this product to your
local supplier upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more information
see: www.recyclethis.info.
device is in compliance with the essential requirements and other
relevant provisions of Directive 2004/108/EC.
