OPERATING YOUR WINE COOLER

Temperature Control
Your wine cooler has one control panel for regulating the
temperature. The temperature control panel is located on
the left center of the wine cooler.
To turn on the wine cooler, press the "Power" button
located on the control panel. If correctly powered on, a
green light will illuminate the "Power" button.
The temperature of the wine cooler is pre-set by the
manufacturer at 54°F (12°C). To increase or decrease the
temperature to desired level, press "
control panel to adjust the temperature setting.
The wine cooler uses semi-conductor cooling technology.
For optimal performance of the appliance, we recommend
that the wine cooler be installed in a location where the
ambient temperature will be between 55°F (12.8°C) ~ 77°F (25°C). The operating temperature
range of the wine cooler temperature control is from 46°F (8°C) ~ 65°F (18°C), +/- 3°C. Please
be advised that the ambient temperature of the wine cooler will affect the internal temperature of
the cooler. Cooler ambient temperature will result in a cooler operating internal temperature and
warmer ambient temperature will result in a warmer operating internal temperature.
To select Celsius (°C) or Fahrenheit (°F), press the "Temp" button on the operation panel.
Temperature Recommendations:
Red Wine: 57°F ~ 65°F (14°C ~ 18°C)
White Wine: 48°F ~ 54°F (9°C ~ 12°C)
NOTE;
If the unit is unplugged, loses power; you must wait 3 to 5 minutes before restarting the
unit. If you attempt to restart before this time delay, the wine cooler may not start.
If there are no items inside the wine cooler, it may take approximately 3 ~ 4 hours to
reach the desired temperature setting.
The wine cooler is designed to fit eight standard unopened wine bottles. Bottles of
different sizes or opened bottles may need to be positioned at different angles and
therefore affect the storage capacity of the wine cooler.
Changing The Inner Light
Prior to changing the inner light of the wine cooler, please contact our Customer Service
Dept. at 888 775-0202 to order replacement LED board with a representative.
Before removing the inner light, turn off the wine cooler first and then unplug the unit from the wall
outlet. Failure to do so could result in electrical shock or personal injury.
Use Phillips screwdriver to take out the screw.
Remove the transparent light cover by pulling downwards gently.
Pull out the two connectors and remove the LED board.
Replace with a new LED board that is the same shape and size
Replace the transparent light cover and tighten screw.
+ -
" or " " button on the
