Piscineo LB1036 Instrucciones De Instalación Y Montaje
Escalera sobre tierra
Resumen de contenidos para Piscineo LB1036
- Página 1 ABOVE GROUND LA D D E R A - F RAME LADDER & DECK TO POOL OWNERS GUIDE & WA R RA N T Y Cat. No. LB1036...
- Página 2 CONSUMER INFORMATION INSTRUCTIONS SAFETY INSTRUCTIONS Above Ground Ladder (Deck to Pool or A-Fr a m e ) I M P O RTANT INSTRUCTIONS Read all instructions completely to become familiar with the assembly process. Failure to follow these assembly and safety i n s t ructions may result in serious personal injury.
- Página 3 P R E PA R AT I O N S P R E PA R A C I O N E S ADDITIONAL MATERIALS (Not supplied with ladder) M ATERIALES ADICIONALES (No incluidos con la escalera) - 2 common bricks - 2 ladrillos norm a l e s - 2 patio blocks ( or 2 more bricks) - 2 piedras de patio (o 2 ladrillos más)
- Página 4 1/4” NYLOCK CAP NUT...
- Página 5 Bolt hole locations for height adjustment. Interior base shown. Note: Both interior and exterior base/ladder assembly's are to be adjusted in an identical manner. Localisation des trous pour ajustement de la hauteur. Vu de la base intérieure. Note : Les assemblages comprenant le socle de base et l’échelle doivent être ajustés de façon identique, qu’ils soient à...
- Página 6 Step 5: Attach fin to back of ladder with four bolts, washers, andnylon cap nuts. A - Frame Step 6A: Slide handles onto top of ladder. Attach with four bolts, washers, and Adjust position of fin to allow ladder base to set on pool bottom, with a bit of clearance between fin and bottom of pool.
- Página 7 Less than 4inches to wall Menos de 4 pulgadas de la pared. Moins de 4 pouces du Deck to Po o l Important! Be certain to position ladder such that the distance Step 7: Set ladder into pool. Mark and drill two 5/16” holes in top rail or deck, to from the pool wall to the fin is less than 4 inches but not align with the holes in the handles.
- Página 8 A - Frame A - Frame Step 8: S u p p o rt pole base on patio blocks or bricks. Measuere pole lengths and Step 9: Assemble exterior ladder base to ladder. Slide base into slots in ladder. cut to fit. Install poles into holes in lad-der deck and into pole base. Attach ladder Align holes for proper height of pool.
