En
the scale of Guard Comb A: 1mm-10mm
(0.5mm/level, 19 levels in total); the scale of
Guard Comb B: 11mm -20mm (0.5mm/level, 19
levels in total); bare metal cutting size:
figure 1
CUTTER HEAD
INSTALLATIONAND
REMOVAL
1. The removal method of the cutter head is
shown in Figure 3 on the right, and gently push
up against the cutter head part on the back of
the trimmer.
2. As shown in Figure 4 on the right of the
cutter head installation method, gently press
down along the sockets on both sides.
figure 3
5
CLEANING
To maintain optimum performance, equipment
should be cleaned after each use.
1. Use the cleaning brush provided to clean the
residual hair on the blade;
2. Remove the Guard Combs, the Guard Combs
can be rinsed under running water, make sure
figure 2
they are thoroughly dry before storage or
further use.
3. Oil the blades only when necessary or about
once a month.
4. Do not rinse the blade.
MAINTENANCE
1.For best results, oil the blades only when
necessary or about once a month. The motor
bearings are permanently lubricated, do not
attempt to oil. When oiling the trimmer, hold the
unit so the blades face down , squeeze three
drops on the front of the blade and one drop on
each side of the heel of the blade, turn on the
machine and wait 3 seconds, then turn off and
wipe off excess oil with a soft cloth. Be careful
not to add too much oil! If too much oil or liquid
Seeps back into the motor and can cause
damage.
2. The blade has precision hardened, ground
and lapped cutting teeth. Blades should be
figure 4
handled with care and never bumped or used to
cut dirty or abrasive materials.
3. Before storing the trimmer, use the cleaning
brush to remove any loose hair from the unit
En
