Replacing the die
(ABLK18-1.3CSE AS(**)) (figure 8).
Loosen the union nut, then pull out the die.
Remove the die and mount a new one.
Tighten the union nut.
Replacing the die
(ABLK18-1.6E AS (**)) (figure 9).
Loosen the screw, then pull out the die.
Remove the die and mount a new one.
Tighten the screw.
Fig. 8
Union nut
Fig. 9 6 mm
Die
3.
4.
2.
1.
Screw
en
19
Die
5.
6.
