Diferenciales Del. Y Tras - Hpi Racing Savage X 4.6 Rtr Manual De Instrucciones

3-12
Front and Rear Differential Maintenance
Mantenimiento diferenciales del/tras.
x2
87194
Shaft For 4 Bevel Gear Diff 4x27mm
Eje para dif. de 4 satélites 4x27mm
x2
x4
Z260
Z529
Pin 2.5x12mm
Flat Head Screw M3x15mm
Pasador 2,5x12mm
Tornillo avellanado M3x15mm
x2
x2
Z892
Washer 5x7x0.2mm B032
Arandela 5x7x0,2mm
Ball Bearing 10x16x5mm
Rodamiento 10x16x5mm
x4 x4
b d
86827 86827
Differential Plate 8x13x2.5mm Washer 4x10x0.15mm
Placa diferencial 8x13x2,5mm Arandela 4x10x0,15mm
x4
x2 6811
O-Ring 6x9.5x2mm
Torica 6x9,5x2mm
c
86827
Washer 6x19x0.2mm
Arandela 6x19x0,2mm
x4
x2
b
86032
Bevel Gear 10 Tooth
a
86032
Satélite 10 dientes
Bevel Gear 20 Tooth
Satélite 20 dientes
x1
86099
Diff Case Washer 0.7mm
Junta diferencial 0,7mm
x1
a
86827
Differential Case
Caja diferencial
x1
86030
Bevel Gear 43 Tooth
Corona diferencial
Screwdriver
Destornillador
86827 b
86827 d
86032
87194
86032 b
86827 b
86827 d
a
86032
Z260
c
86827
6811
a
86827
Z892
B032
86278
6811
5-3 Refer to Exploded View
Ver despiece
Z164
Grease
Grasa
b
86030
86032 b
86827 d
86827 b
86827 b
86032 b
86827 d
87194
Z164
Grease
Grasa
For differential installation see Section 3-11
Para montar el diferencial vea sección 3-11
28
a
86032
Z260
c
86827
6811
Z892
B032
86278
6811
Z529
Z159
Thread Lock
Fija tornillos
86099
Z164
Grease
Grasa
