General Maintenance; Protecting The Environment - Ego Power+ LT1000E Manual Del Usuario

Brightness adjustment
EN
◾
Press the "+" button to increase brightness and press
the "-" button to decrease the brightness.
◾
Press and hold the "+" button for 2-3 seconds and
the brightness will switch into "BOOST" mode, i.e. the
maximum brightness.
◾
When in "BOOST" mode:
- Press the "-" button and the brightness will return
to the previous level.
- To prevent overheating, the light will automatically
shift down to the brightness level 5 (6,400lm) after
about an hour of operation in "BOOST" mode. If this
happens, allow the light to cool down and try to
activate the "BOOST" mode again.
Panel selection
◾
Press the "PANEL SELECT" button to toggle between:
- All four panels are on;
- Only the side panels and the upper panel are on;
- Only the upper panel is on.
◾
Press and hold the "PANEL SELECT" button for 2-3
seconds and the light will switch into "Emergency"
mode, i.e. all FOUR panels will be flashing.
◾
When in "Emergency" mode, press any button (power
button excluded) and the light will resume previous
brightness setting and panel selection.
USB port
The USB port provides charging power of 5 Volts DC at
up a combined draw of 1.5 Amperes for your USB devices.
AUTOMATIC SHUTOFF (Fig. E)
This area light features an automatic shutoff switch that
will turn the light off if upper panel is folded within 10±5°
from the lower panel.
USING THE LIGHT (Fig. F1-F3)
WARNING:
Ensure the light is securely installed
to prevent falling object hazard. Failure to follow the
instruction can result in serious personal injury.
◾
To hang the light, pull out the hooks located in the
base of the unit and hang the light upside down.
◾
To mount the light to a tripod (not included), secure
the tripod screw to one of the tripod mounting holes on
the bottom of the base.
◾
For portable illumination, carry the light by top
handle.
6
56 VOLT LITHIUM-ION CORDLESS PORTABLE AREA LIGHT-LT1000E
MIANTENANCE
WARNING:
When servicing, use only identical
replacement parts. Use of any other parts may create a
hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualified
service technician.
WARNING:
To prevent serious personal injury,
remove the battery pack from the tool before servicing,
cleaning, or removing material from the unit.

GENERAL MAINTENANCE

Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their
use. Use of a piece of clean cloth to remove dirt, dust, oil,
grease, etc.
WARNING:
Do not at any time let brake fluids,
gasoline, petroleum-based products, penetrating oils,
etc. come in contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which may result in
serious personal injury.
TRANSPORTING THE UNIT (Fig. G)
1. Fold the panels and hooks into storage position.
2. Carry the light by the main handle. Main handle can
be pivoted within 215° range and fixed at a desired
angle by the lock-knob if necessary.
STORING THE UNIT
1. Fold the panels and hooks into storage position.
2. Store the light in a dry, well-ventilated area, out of
the reach of the children. Do not store the light on or
adjacent to fertilizers, gasoline, or other chemicals.

PROTECTING THE ENVIRONMENT

Do not dispose of electrical equipment,
used battery and charger into household
waste! Take this product to an authorized
recycler and make it available for
separate collection. Electric tools must be
returned to an environmentally
compatible recycling facility.
