Please read completely through the instructions and verify that all listed parts and hardware are present
before beginning assembly.
(1) Cam Lock
(Qty. 34+1 extra)
(4) Door Stopper
(Qty. 1)
(7) M3.5 x 15 mm Zinc Screw
(Qty. 12+1 extra)
(10) Shelf Support
(Qty. 4+1 extra)
(not included)
Tools required
Parts and Hardware List
(2) Cam Bolt
(Qty. 34+1 extra)
(5) M3 x 15 mm Screw
(Qty. 2+1 extra)
(8) Handle with Metal Plate
(11) Cam Lock Cover
Tipping Restraint Hardware Kit (Qty. 1)
(Included in plastic bag)
: Phillips screwdriver, stud finder, pencil, tape measure, power drill and 1/8" drill
(Qty. 1)
(Qty. 38+1 extra)
bit.
6
(3) M8 x 30 mm Wood Dowel
(Qty. 36+1 extra)
(6) Door Hinge
(Qty. 2)
(9) 5/32" x 28 mm Bolt
(Qty. 2)
(Qty. 1)
Glue
