JB 12 CFM Manual De Instrucciones

CONTENTS – DV-340N 12 CFM PLATINUM BEAST VACUUM PUMP
Introduction
Motor Specifications
Operation
Pump Maintenance
Repair
Troubleshooting
Return for Repair
Warranty
Lift ring for easier hoisting
Angled easy access 1/4", 3/8" or 1/2" intake tee
Gas ballast for extended oil life
Illuminated low profile
rocker switch
1 HP DC motor with
broad operating
voltage range
Four point stable base
WARNING: UNIT DRAINED OF OIL
FOR SHIPMENT. DO NOT OPERATE
WITHOUT ADDING OIL.
2
2
2
2
3
4
4
4
All metal construction with finned aluminum
housing for heat dissipation, brass fittings and
stainless steel valving
Ergonomic 1/2" NPT break resistant handle
Oil mist filter
controls exhaust
DV-340N PLATINUM
OPERATING MANUAL
Large diameter oil fill opening
Large oil level sight glass
O-ring sealed oil drain
valve to prevent leaks
BEAST 12 CFM VACUUM PUMP
®
CFM 12 CFM (340 l/m)
MOTOR 1 HP, DC
VOLTAGE 115v/230v
INTAKE PORT 1/2" x 1/4" x 3/8"
OIL CAPACITY 32 oz
WEIGHT 34 lb
