Adhoc Message Recording - Optimus Dc-700Eth/T Manual De Instalación

DC-700ETH/T

5.5. Adhoc message recording

Adhoc messages are specific messages, recorded for a specific purpose and usually not generalizable. They are recorded
from the DC-700ETH/T desk and their usefulness is usually temporary.
Once recorded, you can use the Adhoc message as any other pre-recorded message of the DC-700ETH/T (see section
Send a prerecorded message
The priority of the DC-700ETH/T Adhoc messages with respect to the rest of the messages and sound sources of the system,
is predetermined by the priority of the sound source assigned to the DC-700ETH/T when configuring it through the Call
Point or CallPoint Configurator software. If necessary, it can be modified through the same software.
When recording an Adhoc message, if the DC-700ETH/T belongs to a Global Area, the message will be stored in the ADHOC
COMMON folder. If the DC-700ETH/T belongs to a Local Area, the message will be stored in the ADHOC AREA folder.
Recording procedure:
1. Long press and hold on any point in an area free of elements
and a circular selection menu will appear.
2. Select Adhoc.
3. Press to start recording.
4. Press to end the recording.
5. If you wish, you can use the PLAY- PAUSE- STOP controls to monitor the message you have just recorded. If the
recording volume is not adequate, you can modify it by following the section
6. Enter a name for the message, and select an empty slot
overwrite the file. There are 20 slots available for saving Adhoc messages.
7. Click on Save.
Configuration and User Manual. Version 5.2.001
DC-700ETH/T.
).
Message monitoring
controls
(PLAY - PAUSE - STOP)
Configuration and user's manual
3.3.1.3. Adjusting the microphone
[Empty] to add the message, or one of the occupied slots to
Empty slot.
Select to add a new
Adhoc message to the
list.
R+D Department
5. BASIC OPERATIONS
volume.
SLOTS Occupied)
5.2.
35
