19. FR (Fast Reverse)
Press this button to search disc
backward continuously. There are 5
speed options to choose: 2X, 4X, 8X, 16X,
and 32X.
20. FF (Fast Forward)
Press this button to search disc forward
continuously. There are 5 speed options
to choose: 2X, 4X, 8X, 16X, and 32X.
21. SETUP
Navigate the Setup Menu. Please refer
to the following pages to confi gure
the system: General Setup Page, Audio
Setup Page, Preference Page, and
Password Setup Page.
22. EJECT
Eject the disc from the disc
compartment or load the disc into the
disc compartment.
23. TV-Monitor B
Function not available at this time.
24. DVD-Monitor B
Transmit IR codes for DVD mode of
Monitor B.
25. SOUND AROUND SELECT (If available)
Select a FM transmitter channel. There
are 6 channels: CH1: 88.3MHz; CH2:
88.7MHz; CH3: 89.1MHz; CH4: 89.5MHz;
CH5: 89.9MHz; CH6: 90.3MHz.
26. PIX (Picture Selection)
Each time the button is pressed, the
picture adjustment OSD cycles through
bars for BRIGHTNESS, CONTRAST,
SATURATION, HUE, SHARPNESS, IR
HEADPHONE, and RESET. Once the
desired adjustment bar is displayed,
use the UP/DOWN button to
adjust the setting. The bar display
will automatically disappear, if no
adjustments are made within 6 seconds
or if any button is pressed.
16
Button Function Descriptions
27. REPEAT
Press this button to switch the repeat
mode by ALL, TITLE, CHAPTER and
cancel the repeat mode while playing
DVD-video. Other disc types such as
VCD, CD, and SVCD that only have two
repeat modes that can be selected:
TRACK and ALL
Note: Both repeat functions of VCD and
SVCD need the PBC status set to ON
when available.
28. A-B (Except MP3)
Repeat from point A to point B.
29. R-S (If TV mode is available)
Function not available at this time..
30. ERASE/ADD
Function not available at this time.
31. AUDIO
Press this button if the current disc
has diff erent language options. Press
this button repeatedly until you have
reached your desired language option.
32. ANGLE
View with a diff erent camera angle (The
button takes eff ect only on the DVD that
supports frames with multiple angles).
Press this button repeatedly until you
have reached your desired viewing
angle.
