Switch to PC x by Keyboard Hotkeys
Hit the hotkey according to your current hotkey definition:
Hotkey sequence = Ctrl + Alt + [command key]*
* The factory default hotkey setting is Ctrl + Alt + 1/2/3/4 for PC 1/2/3/4. You can also
use ScrLk + ScrLk to switch PC.
Start Auto-scan
Right-click the KVM Switcher icon to evoke the operation menu, then select
Start Auto-Scan to activate autoscanning.
Stop Auto-scan
(While autoscanning) right-click the KVM Switcher icon to evoke the
operation menu, then select Stop Auto-Scan to de-activate autoscanning.
KVM Switcher configuration
Right-click the KVM Switcher icon and select Settings or double-click the
icon to bring up the configuration dialog box.
Define Hotkey commands
You can specify the command key as you like by typing it in. For example,
you can specify the hotkey for switching to PC 1 as CTRL + ALT + A by
typing an A (not case-sensitive) in the editable field.
Hotkey Sequence = CTRL + ALT + [command key]*
* The command key is user-definable via the configuration dialog box
Except those control keys such as Alt, Ctrl, Shift, CAPS, Tab, Esc and
those functions keys and edit keys, all other keys on the keyboard,
including those number keys on the number pad are all qualified to be used
a hotkey command key. In addition to the software KVM Switching by the
operation menu and the user-defined hotkeys, you can always use the
universal hotkey for PC switching – ScrLk + ScrLk
