With optional pedestal base or stacking kit

Required Dimensions for Installation With Pedestal
Required Dimensions for Installation With Stacking Kit
WF501ANW-03010B_EN.indd Sec3:15 WF501ANW-03010B_EN.indd Sec3:15
51.2 in. (130 cm) to clear open door
341.1 in.
(86.5 cm)
48 in.² *
(310 cm²)
24 in.² *
(155 cm²)
Closet or Door
6 in. *
(15.2 cm)
77.2 in.
(196.2 cm)
1 in. 27 in.
(2.5 cm) (68.6 cm)
4 in. 27 in.
(68.6 cm)
(10 cm)
3 in.
(7.6 cm)
3 in.
(7.6 cm)
1 in. 34.1 in.
(2.5 cm) (86.5 cm)
* Required spacing
** External exhaust elbow requires additional
space.
installing your washer _15
38.6 in.
(98.1 cm)
53.6 in.
(136.2 cm)
2.5 in.
(6.3 cm)
5.5 in.**
(14 cm)
