IntesisBox KNX - EnOcean
Status_ Vane Position 3
Status_ Vane Position 4
Status_ Vane Position 5
Status_ Vane Swing
Status_ Setpoint
Temperature
Status_ Setpoint
Status_ Temperature
Alarm Status_ Alarm State
Error Status_ Error code
Status_ Window Contact
Window
Status_ Window Contact
Status_ External disablement
External
Status_ External disablement
Status_ Disable Remote Control
Locking
Status_ Disable Remote Control
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 bit DPT_Bool
1 byte DPT_Scaling
2 bytes DPT_Value_Temp
2 bytes DPT_Value_Temp
1 bit DPT_Alarm
2 bytes DPT_Value_2_Ucount
1 bit DPT_OpenClose
1 bit DPT_Window_Door
1 bit DPT_Bool
1 bit DPT_Enable
1 bit DPT_Bool
1 bit DPT_Enable
1.002 R T 1 - Position 3
1.002 R T 1 - Position 4
1.002 R T 1 - Position 5
0 – Position 1; 1 - Swing
1.002 R T
5.001 R T (ºC)
9.001 R T (ºC)
9.001 R T (ºC)
0 – No alarm; 1 - Alarm
1.005 R T
7.001 R T AC error (0 - no error)
1.009 R T 0 - Open; 1 - Closed
1.019 R T 0 - Closed; 1 - Open
1.002 R T 0 - False; 1 - True
1.003 R T 0 - Disable; 1 - Enable
1.002 R T 0 - False; 1 - True
0 - Disable; 1 – Enable
1.003 R T
